SLAB GATE VALVE
2"–24", Class 150–600 slab gate valve with symmetrical bidirectional sealing, metal-to-metal gas-tight sealing, and low life-cycle cost.
Product Details
OVERVIEW
The SLab Gate Valve incorporates a one-piece floating slab gate combined with floating seats and a spring-loaded, pressure-energized stem seal to deliver symmetrical bidirectional sealing without pressure trapping. A single pressure-energized PEEK lip seal at the seat-to-body interface maintains the primary body seal, while metal-to-metal seating surfaces provide gas-tight isolation without the need for sealants.
Available from 2" to 24" in Class 150–600 with RF, RTJ, and BW end connections, the SLab Gate Valve is designed for exceptional service life with minimal maintenance and a low life-cycle cost compared to alternative valve designs. Body materials include carbon steel, stainless steel, alloy steel, specialty alloys, and Al-bronze. Certified to NACE MR0175, CE/PED, ISO, ATEX, SIL, and Fire Safe.
SLab Gate Valve
2"–24", Class 150–600 slab gate valve with symmetrical bidirectional sealing, metal-to-metal gas-tight sealing, and low life-cycle cost.
Symmetrical Bidirectional Sealing
Floating slab gate and seat design delivers bidirectional sealing while preventing pressure trapping in the body cavity.
Metal-to-Metal Gas-Tight Sealing
Seating surfaces achieve gas-tight isolation without injectable sealants, reducing maintenance requirements.
Pressure-Energized Stem Seal
Spring-loaded stem seal requires no longitudinal preload and self-energizes with line pressure for zero fugitive emissions.
PEEK Lip Seal
Single pressure-energized PEEK lip seal at the seat-to-body interface provides robust, long-life primary body sealing.
Low Life-Cycle Cost
Minimal maintenance requirements and long service life deliver a lower total cost of ownership compared to competing designs.
SPECIFICATIONS
GENERAL
2 SPECSMATERIALS
2 SPECSEND CONNECTIONS & ACTUATION
2 SPECSSTANDARDS & CERTIFICATIONS
2 SPECSUse Cases
APPLICATIONS
Engineered for demanding environments across multiple industries and operating conditions.
REQUEST A QUOTE
Contact Athena Control for pricing, availability, and technical support for the SLab Gate Valve.
